125mm Nylon Wheel 330Kg Capacity Castor (S516B)

The S516B manufactured by Richmond Rolling Solutions is a swivel frame castor and is fitted with a nylon wheel. This swivel castor is in our heavy duty welded series range and has a maximum capacity of 330kg. The S516B is assembled with ball bearings on the castors axle. The swivel frame design of this castor allows full swivel rotation to enable steering. The overall nylon wheel diameter is 125mm, the wheel width is 35mm and you can order separately (Part Number: NY513).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.

Product Code	S516B
Wheel Diameter (mm)	125
Frame Type	Swivel with Brake
Wheel Width (mm)	35
Wheel Type	Nylon
Wheel Code	NY513
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	159
Swivel Radius (mm)	102
Maximum Load Capacity (kg)	330
Recommended Load Capacity (kg)	250
