75mm Nylon Wheel 125Kg Capacity Castor (S323B)

The S323B manufactured by Richmond Rolling Solutions is a swivel frame castor and has a nylon wheel. This swivel castor is in our heavy duty welded series range and has a maximum capacity of 125kg. The S323B wheel is fitted with plain bearings. This castors swivel frame allows full swivel rotation to enable steering. The outside diameter of the nylon wheel is 75mm, the wheel width is 30mm and can be ordered separately (NY3321).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.

Product Code	S323B
Wheel Diameter (mm)	75
Frame Type	Swivel with Brake
Wheel Width (mm)	30
Wheel Type	Nylon
Wheel Code	NY3321
Wheel Bearing Type	Plain Bore
Castor Height (mm)	114
Swivel Radius (mm)	76
Maximum Load Capacity (kg)	125
Recommended Load Capacity (kg)	100

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
