230mm Cushion Rubber 220kg Capacity Castor
Model Number: S9010
Frame Type: Swivel
- Swivel
- Rigid
- Ships worldwide
- OEM & custom builds
Prefer to talk? Phone +84 028 6287 6012 · WhatsApp +61 417 368 015
Key specifications
| Product Code | S9010 |
|---|---|
| Wheel Diameter (mm) | 230 |
| Frame Type | Swivel |
| Wheel Width (mm) | 40 |
| Wheel Type | Cushion Rubber |
| Wheel Code | CR9000 |
The S9010 manufactured by Richmond is a swivel frame castor and uses a cushion rubber wheel. This swivel castor is part of our 500 series range and can safely take loads up to 220kg. The S9010 is assembled with ball bearings on the castors axle. The swivel frame allows the load to be steered. The diameter of the cushion rubber wheel is 230mm, the wheel width is 40mm and can be ordered separately (CR9000). For the same castor with a brake, see S9010B.
View Specifications
| Product Code | S9010 |
|---|---|
| Wheel Diameter (mm) | 230 |
| Frame Type | Swivel |
| Wheel Width (mm) | 40 |
| Wheel Type | Cushion Rubber |
| Wheel Code | CR9000 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 294 |
| Swivel Radius (mm) | 175 |
| Maximum Load Capacity (kg) | 220 |
| Recommended Load Capacity (kg) | 180 |
| Towable | Yes |
Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
