230mm Cushion Rubber 220kg Capacity Castor (S9010)

The S9010 manufactured by Richmond is a swivel frame castor and uses a cushion rubber wheel. This swivel castor is part of our 500 series range and can safely take loads up to 220kg. The S9010 is assembled with ball bearings on the castors axle. The swivel frame allows the load to be steered. The diameter of the cushion rubber wheel is 230mm, the wheel width is 40mm and can be ordered separately (CR9000). For the same castor with a brake, see S9010B.

View Specifications View Specifications Shipping Information

Specifications

Product Code	S9010
Wheel Diameter (mm)	230
Frame Type	Swivel
Wheel Width (mm)	40
Wheel Type	Cushion Rubber
Wheel Code	CR9000
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	294
Swivel Radius (mm)	175
Maximum Load Capacity (kg)	220
recommended-load-capacity-kg
Towable	Yes
