200mm SG Iron Wheel 1500kg Capacity Castor (S837SG)

The S837SG manufactured by Richmond is a swivel frame castor and is fitted with a semi pneumatic wheel. This swivel castor is one of our high performance series range and has a top load capacity of 1500kg. The S837SG uses ball bearings for wheel rotation. The swivel frame design of this castor permits the load to be steered. The diameter of the semi pneumatic wheel is 200mm, the wheel width is 75mm and you can order separately (Part Number: SG834).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

When performance and endurance are key concerns, the High Performance castor is world class. A large opposed taper roller bearing in the swivel head means the castor can be power towed at speeds up to 12kph over flat surfaces without obstructions. The steel passivated zinc plated frame is robot welded and a fully sealed greasable swivel head make this castor easy to maintain. Richmond’s High Performance Series is custom designed and manufactured in-house to specification.

Product Code	S837SG
Wheel Diameter (mm)	200
Frame Type	Swivel
Wheel Width (mm)	75
Wheel Type	SG Iron
Wheel Code	SG834
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	264
Swivel Radius (mm)	172
Maximum Load Capacity (kg)	1500
Towable	No

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
