150mm Cast Iron Wheel 1000kg Capacity Castor (S631SG)

The S631SG manufactured by Richmond is a swivel frame castor and is fitted with a cast iron wheel. This swivel castor is part of our high performance series range and has a top load capacity of 1000kg. The S631SG wheel is fitted with ball bearings. The swivel frame design of this castor allows the castor to swivel 360°. The diameter of the cast iron wheel is 150mm, the wheel width is 45mm and can be ordered separately (Ci601).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

When performance and endurance are key concerns, the High Performance castor is world class. A large opposed taper roller bearing in the swivel head means the castor can be power towed at speeds up to 12kph over flat surfaces without obstructions. The steel passivated zinc plated frame is robot welded and a fully sealed greasable swivel head make this castor easy to maintain. Richmond’s High Performance Series is custom designed and manufactured in-house to specification.

Product Code	S631SG
Wheel Diameter (mm)	150
Frame Type	Swivel
Wheel Width (mm)	45
Wheel Type	Cast Iron
Wheel Code	Ci601
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	214
Swivel Radius (mm)	135
Maximum Load Capacity (kg)	1000
Towable	No

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
