125mm Nylon Wheel 20kg Capacity Spring Loaded Gate Castor (S5024)

Richmond’s Spring Loaded Gate Castors are designed to make opening and closing of residential gates easier. The spring-loaded design provides shock absorption features specifically for use on uneven surfaces. The gate mount is integrated into the frame of the castor for easy fixing to any gate system. S5024 has been designed for use on platform ladders that require maneuverability combined with locking under load.

The S5024 by Richmond is a swivel frame castor and is fitted with a nylon wheel. This swivel castor is in our spring loaded gate range and has a maximum capacity of 20kg. The S5024 wheel is fitted with plain bearings. The swivel frame permits the load to be steered. The outside diameter of the nylon wheel is 125mm, the wheel width is 30mm and you can order separately (Part Number: NY5517).

View Specifications View Specifications Shipping Information

Specifications

Product Code	S5024
Wheel Diameter (mm)	125
Frame Type	Swivel with Exposed Spring
Wheel Width (mm)	30
Wheel Type	Nylon
Wheel Code	NY5517
Wheel Bearing Type	Plain Bore
Castor Height (mm)	159
Swivel Radius (mm)	102
Bolt Size	M12
Maximum Load Capacity (kg)	20

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
