125mm Cast Iron Wheel 380Kg Capacity Castor (S533CI)

The S533CI by Richmond Rolling Solutions is a swivel frame castor and is fitted with a cast iron wheel. This swivel castor is one of our heavy duty welded series range and has a top load capacity of 380kg. The S533CI uses plain bearings for wheel rotation. This castors swivel frame allows for full 360° swivel rotation. The overall cast iron wheel diameter is 125mm, the wheel width is 38mm and you can order separately (Part Number: Ci532).

View Specifications View Specifications Shipping Information

Specifications

Product Code	S533Ci
Wheel Diameter (mm)	125
Frame Type	Swivel
Wheel Width (mm)	38
Wheel Type	Cast Iron
Wheel Code	Ci532
Wheel Bearing Type	Plain Bore
Castor Height (mm)	159
Swivel Radius (mm)	102
Maximum Load Capacity (kg)	380
Recommended Load Capacity (kg)	280

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
