100mm Nylon Wheel 300Kg Capacity Castor (S416NY)

The S416NY from Richmond is a swivel frame castor and features a nylon wheel. This swivel castor is in our heavy duty welded series range and can hold loads up to 300kg. The S416NY wheel is fitted with ball bearings. This castors swivel frame allows full swivel rotation to enable steering. The diameter of the nylon wheel is 100mm, the wheel width is 35mm and you can order separately (Part Number: NY413).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.

Product Code	S416NY
Wheel Diameter (mm)	100
Frame Type	Swivel
Wheel Width (mm)	35
Wheel Type	Nylon
Wheel Code	NY413
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	132
Swivel Radius (mm)	90
Maximum Load Capacity (kg)	300
Recommended Load Capacity (kg)	200

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
