300mm Twin Wheel Swivel Extra High Perf Castor (S1237B)

The S1237B by Richmond is a swivel frame castor and features 2 polyurethane tyred cast iron wheels. This swivel castor is one of our extra high performance series range and has a maximum capacity of 2500kg. The S1237B wheel is fitted with taper roller bearings. The swivel frame design of this castor permits the load to be steered. The outside diameter of the polyurethane tyred cast iron wheels is 300mm, the wheels width is 2 x 50mm and you can order separately (Part Number: PU1218).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

In a class of its own, the EHP series outperforms all rivals no matter how tough the circumstances. Developed using Richmond’s 6 decades of castor know how, features include a large opposed taper roller bearing swivel head and precision robot welded fully sealed construction to give a long life without costly breakdowns. The EHP series are fully towable at speeds up to 16kph on flat surfaces without obstacles, making them ideal for work in heavy duty applications. The castor’s twin wheel design not only increases surface contact but controls the rolling speed of each wheel when turning and manoeuvering. Custom designed and manufactured in-house, we challenge you to find a better castor.

Product Code	S1237B
Wheel Diameter (mm)	300
Frame Type	Swivel with Brake
Wheel Type	Twin Polyurethane Tyred Cast Iron Centred
Wheel Code	PU1218
Wheel Bearing Type	Taper Roller Bearing
Castor Height (mm)	420
Swivel Radius (mm)	240
Maximum Load Capacity (kg)	2500

Australian Manufactured

Swivel with Brake

Towable
