250mm Twin Poly CI Wheel 1300kg Capacity Castor (S1090B)

The S1090B from Richmond Rolling Solutions is a swivel frame castor and features 2 polyurethane tyred cast iron wheels. This swivel castor is one of our high performance series range and has a top load capacity of 1300kg. The S1090B uses ball bearings for wheel rotation. The swivel frame of this castor allows the castor to swivel 360°. The diameter of the polyurethane tyred cast iron wheels is 250mm, the wheels width is 2 x 75mm and can be ordered separately (PU1076).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

When performance and endurance are key concerns, the High Performance castor is world class. A large opposed taper roller bearing in the swivel head means the castor can be power towed at speeds up to 12kph over flat surfaces without obstructions. The steel passivated zinc plated frame is robot welded and a fully sealed greasable swivel head make this castor easy to maintain. Richmond’s High Performance Series is custom designed and manufactured in-house to specification.

Product Code	S1090B
Wheel Diameter (mm)	250
Frame Type	Swivel with Brake
Wheel Width (mm)	75 x 2
Wheel Type	Twin Wheel Polyurethane Tyred Cast Iron Centred
Wheel Code	PU1076 x 2
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	312
Swivel Radius (mm)	210
Maximum Load Capacity (kg)	1300
Towable	Yes

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
