250mm SG Iron Wheel 1500Kg Capacity Castor (S1032B)

The S1032B by Richmond is a swivel frame castor and uses a semi pneumatic wheel. This swivel castor is part of our forged head series range and has a top load capacity of 1500kg. The S1032B wheel is fitted with ball bearings. The swivel frame of this castor permits the load to be steered. The diameter of the semi pneumatic wheel is 250mm, the wheel width is 75mm and you can order separately (Part Number: SG1027). For the same castor without a brake, see S1032.

View Specifications View Specifications Shipping Information

Description
Specifications

Description

Applications including transport and logistics, heavy machinery, warehousing equipment and mobile platforms rely on the extreme shock loading, robust durable king pin, drop forged steel baseplate of Richmond’s Forged Head Series for loads up to 1500kg. Truly a great all round castor for those heavy duty applications requiring a towable option, zinc plated for corrosion resistance and the ability to withstand daily abuse that will not compromise performance.

Product Code	S1032B
Wheel Diameter (mm)	250
Frame Type	Swivel with Brake
Wheel Width (mm)	75
Wheel Type	SG Iron
Wheel Code	SG1027
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	317
Swivel Radius (mm)	194
Maximum Load Capacity (kg)	1500
Towable	No

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
