250mm Cushion Rubber 300kg Capacity Castor (S1025D)

The S1025D by Richmond Rolling Solutions is a swivel frame castor and is fitted with a cushion rubber wheel. This swivel castor is part of our 500 series range and has a maximum capacity of 300kg. The S1025D is assembled with ball bearings on the castors axle. The swivel frame allows the castor to swivel 360°. The cushion rubber wheel diameter is 250mm, the wheel width is 50mm and can be ordered separately (CR1060). To order this castor without the direction lock, search for S1025. This castor includes a directional lock – This feature locks the swivel direction of the castor but still allows the wheel to turn. When the directional lock is released, full swivel function is returned to the castor. Castors with a directional lock are indicated by a ‘D’ at the end of the castor code.

View Specifications View Specifications Shipping Information

Description
Specifications

Description

The 500 Series is designed and manufactured for heavy duty applications including low speed, medium weight towing up to a maximum speed of 6kph. A sealed precision machined ball race ensures the swivel movement is kept clean and smooth. Complete with a high tensile kingpin to withstand high impact side loads, Richmond’s 500 Series moves high demand industries such as; Automotive, Rapid moving production lines and steel manufacturer’s due to the reliability and performance of this robust castor.

Product Code	S1025D
Wheel Diameter (mm)	250
Frame Type	Swivel with Directional Lock
Wheel Width (mm)	50
Wheel Type	Cushion Rubber
Wheel Code	CR1060
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	302
Swivel Radius (mm)	180
Maximum Load Capacity (kg)	300
recommended-load-capacity-kg
Towable	Yes

Swivel with Directional Lock

Towable
