150mm Cast Iron Wheel 300kg Capacity Castor (R6051)

The R6051 from Richmond Rolling Solutions is a rigid frame castor and features a cast iron wheel. This rigid castor is in our 300 series plate range and can hold loads up to 300kg. The R6051 uses plain bearings for wheel rotation and is mounted with the baseplate. This castors rigid frame allows for linear movement and steering can be achieved by using in conjunction with swivel castors. The diameter of the cast iron wheel is 150mm, the wheel width is 45mm and can be ordered separately (Ci611).

View Specifications View Specifications Shipping Information

Description

Meeting and exceeding all performance standards due to a higher load bearing capacity, the 300 Series has a wide range of uses. A nylon wheel in a 300 series is most common for industrial and trolley applications, a rebound rubber wheel is ideal for road cases and transportable crates whilst a poly nylon wheel is best suited to undercover and showroom displays. Cast Iron, Poly Cast Iron and Aluminium wheels are also available with this series.

Product Code	R6051
Wheel Diameter (mm)	150
Frame Type	Rigid
Wheel Width (mm)	45
Wheel Type	Cast Iron
Wheel Code	Ci611
Wheel Bearing Type	Plain Bore
Castor Height (mm)	187
Maximum Load Capacity (kg)	300
Recommended Load Capacity (kg)	225
Temperature range (°C)	-30° to 300°

Download CAD Drawing (STEP file)	Download

-30˚ to 300˚C Wheel Temp

Rigid

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
