High/Low Temp 100mm Wheel | 1/2" Axle Diameter (AL474-50)

100mm diameter wheel manufactured from hardened aluminium
Manufactured with a high-temp aluminium bronze bush & crowned rim profile
Suitable for -30°c to 400+°c extreme heat temperature ranges
Identical wheel to al471 but c/w wider boss width to suit richmond 300 Series & Heavy Industrial castor frames
Optimal wheel for extreme high temperature ovens baking at 400+°c with long baking cycle times
Maximum 180kg load capacity per wheel
Aluminium material withholds heat so is susceptible to damage/marking non-slip or epoxy flooring

View Specifications View Specifications Shipping Information

Specifications

Product Code	AL474-50
Wheel Diameter (mm)	100
Tyre Width (mm)	36
Boss Width (mm)	47
Axle Diameter	1/2 inch (12.7mm)
Wheel Bearing Type	Bronze Bush
Temperature Range	-30° to 400°C
Wheel Type	Aluminium
Maximum Load Capacity (kg)	180
Recommended Load Capacity (kg)	150

-30˚ to 400˚C Wheel Temp

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
