100mm GF Nylon Wheel 200kg Capacity Castor (S4136)

200kg load capacity
Zinc plated corrosion resistant swivel frame
Glass filled nylon wheel
Suitable for extreme temperature ranges between -30°C-280°C
100mm diameter, 35mm width, can be ordered separately (Part Number: GF412)

This castors frame is a swivel frame which allows the castor to swivel or rotate 360° so the load may be steered.

View Specifications View Specifications Shipping Information

Description

Heavy duty pressed stainless steel frame combined with full stainless componentry make the Excel Series the ideal choice for use in wet areas, frequent wash down applications and food and health industries. When hygiene is of the utmost importance, this bolt hole castor has the ability to be fitted to an array of equipment and trolleys with various fittings including; pre fitted threaded inserts, solid drilled metal pintles, expanding pintles or a single bolt.

Product Code	S4136
Wheel Diameter (mm)	100
Frame Type	Swivel
Wheel Width (mm)	50
Wheel Type	Glass Filled Nylon
Wheel Bearing Type	Plain Bore
Castor Height (mm)	130
Swivel Radius (mm)	90
Bolt Hole Size (mm)	12
Maximum Load Capacity (kg)	200
Recommended Load Capacity (kg)	150
Temperature range (°C)	-30° to 240°

Download CAD Drawing (STEP file)	Download

-30˚ to 240˚C Wheel Temp

12mm Bolt Hole

Swivel

Shipping Information

Shipping and lead time information is available upon request. Lead times may vary based on order quantities. For detailed information on our freight charges, click & collect locations, and additional shipping policies please contact us.
